In high-end hospitality environments, fire safety equipment must comply with regulations while preserving the architectural intent. At Pavillon de la Rotonde, the integration of the design fire extinguisher cabinet Harmony illustrates a design-led approach to fire protection in hotel corridors and guest areas.
Project Overview
- Project type: Hospitality – Hotel
- Location: Pavillon de la Rotonde, France
- Application area: Circulation spaces (corridors)
- Constraint: Maintain visual continuity in a highly designed interior
- Solution: Harmony fire extinguisher cabinet with mirror finish door
Architectural & Interior Design Constraints
The interior design of Pavillon de la Rotonde relies on a cohesive material palette and controlled visual atmosphere:
- Decorative wall tapestry with strong graphic identity
- Textured carpet with patterned motifs
- Neutral and soft tonal range
- Low visual tolerance for technical elements
In this context, standard fire equipment (visible extinguishers, red cabinets) would create disruptive visual contrast within circulation areas.
Design Response: Reflective Integration Strategy
The selected configuration uses a silver mirror door, enabling the cabinet to reflect its immediate environment.
- Visual absorption of surrounding materials
- Reduction of perceived volume
- Continuity of textures and light
- Minimal visual impact in guest pathways
This approach allows compliance elements to remain identifiable while significantly reducing their architectural footprint.
Product Specification – Harmony Cabinet
- Structure: Steel cabinet with epoxy powder coating
- Door: Custom finish – silver mirror
- Signage: Integrated laser-cut pictogram with red insert
- Installation: Floor-standing with ballasted base or wall-mounted
- Opening system: Removable cover (top lift + rail guidance system)
Optional configuration includes:
- Totem signage (acrylic – transparent, frosted, mineral finishes)
- Custom materials (metal finishes, synthetic leather, printed surfaces)
- Extended RAL colour matching for structure and base
Technical Characteristics
- Dimensions (cabinet + base): H 770 mm – W 290 mm – D 210 mm
- Height with totem: 1221 mm
- Weight: approx. 11.2 kg
- Compatibility: 6L / 9L extinguishers – CO₂ 2kg
- Material thickness: Steel structure + aluminium door
- Finish: Epoxy powder coating (matt, satin, gloss, fine texture)
- Manufacturing: France
Compliance & Integration Benefits
- Maintains extinguisher accessibility and visibility requirements
- Compatible with ERP hospitality standards
- Reduces visual pollution in high-end interiors
- Adapts to architectural constraints (wall or floor installation)
- Supports design consistency across circulation areas
Note: floor installation must consider compatibility with accessories (totem, rear masking plate) depending on project configuration.
Why Specify Harmony for Hospitality Projects
For architects, interior designers and engineering consultants, Harmony provides a flexible solution where safety equipment becomes part of the design language.
- Wide range of finishes and materials
- Adaptation to luxury and premium environments
- Integration into FF&E and interior detailing strategies
- Consistent design across multiple project zones
Conclusion
At Pavillon de la Rotonde, the Harmony cabinet demonstrates that fire protection can be fully integrated into a refined interior without compromise.
Through reflective finishes and material alignment, safety equipment becomes a discreet architectural component, aligned with the expectations of contemporary hospitality design.
